| Specification of Cheetah i6 |
|
| Motor Type |
DC Brush Motor |
| Power |
650W |
| Max. Output |
1100W |
| Max torque |
15n.m/2500rpm |
| Battery |
48V20AH |
| Max speed |
19 M/H, 13 M/H on low speed mode |
| Climbing ability |
12° |
| Mileage at full charge |
30 Mile |
| Turning Radius |
13.1 feet |
| Gears |
F–R |
| Drive Mode |
CHAIN / DUAL WHEEL DRIVE |
| Suspension, F / R |
DUAL A-ARM / THRU-SHAFT WITH DUAL SHOCKS ARM |
| Brakes |
REAR DISC |
| Tires, F / R |
145/70-6 / 16*6-8 |
| Weight, G.W. / N.W. |
308 / 264 lbs |
| Max load |
180 LBS |
| Dimension Information |
| Wheelbase |
43.7″ |
| OA L x W x H |
63x36x50 inches |
| Height to seat |
14.2 inches |
| Min. ground clearance |
3.6 inches |
| Pedal to seat back |
28” to 32” |
| package size |
60X32X21 inches |
